| Brand Name : | Bett |
| Model Number : | K19 |
| Price : | $0.85-1 |
Product Specification
| Brand | Bett |
| scope of application | the LED industry, Marine, terrestrial heat, street lamp, aquaculture, laser, lighting, furniture, screens and so on |
| Types | waterproof plug/waterproof connectors/waterproof connectors/Multi-split waterproof plug/nylon waterproof plug/fabricated waterproof plug |
| Interface type | AC/DC |
| Shape | round/flat look |
| Process | stamping/welding/injection molding |
| Feature | waterproof |
| Contact material | pure phosphor copper |
| Joint material | PVC/PBT/PA66 / PC + ABS |
| Some conclusions | 2-12 core |
| Pin number | 2-12 needle |
| line length | any (mm) |
| Form | socket, plug stamping or injection after welding |
| Rated voltage | 24 V DC 0 (AC 110 V, 110 V) |
| Current rating | 1-50A |
| Breakdown voltage | 1500 V or higher (special require should be mentioned in advance) |
| Working temperature | - 40 ~ 105 ° C |
| Protection grade | IP65 - IP68 (other requirement. When ordering, please put forward) |
| Wire materials | PVC, rubber, silicone, PE and so on, other according to customer requirements, routine for gb RVV sheath line |
| Certification | can according to customer's requirements with CCC, VDE, UL, ROHS, SGS, etc all kinds of wire |
| Appearance color | black, white, transparent, etc |
| Normal product | joint is made of PVC, wire type for CCC gb RVV sheath line, regular length for each 200 mm Can be designed and manufactured according to customer demand orientation, non-standard products |
| Some conclusions | 2 core |
| Cable inside section | 0.75 square (normal) |
| Cable length | any long can be customized for customer request, (20 cm) regular long male female each When ordering, please indicate some conclusions, insider cross-sectional area square number, color, line length, tail decortication and wetting length (normal is 3 cm and 3 mm), the other orders are required to submit |




Packing :
1.Bundle up into bundles.
2.Paired with cardboard boxes.
3.Load into cardboard box.
4.Loading.
5.transport.





Shenzhen Bett Electronic Co.,Ltd is a leader of a waterproof plug
in China, we have ten years of factory experience, a professional
research team, standardized production workshop.
We are specializing in a series 2-12 pins waterproof connector,
incloding M12, aviation connector, panel mount connector, bulkhead
connector, T/Y type connector(1 input 2-8 output connector), male
to female connector, DC plug, assembled plug, ect.
Above items are applied in the LED industry, Marine, terrestrial
heat, street lamp, aquaculture, laser, lighting, furniture,
screens, the sensors, instruments, new enegry industry, automotive
electronics, industrial automation and so on.
Our company supplies different kinds of products. High quality and
favorable price. We're pleased to get your Inquiry and we will come
back to as soon as possible. We stick to the principle of "quality
first, service first, continuous improvement and innovation to meet
the customers" for the management and "zero defect, zero
complaints" as the quality objective.







|
